Basaran Asphalt Tanker, Bitumen Tanker, is designed to carry asphalt, bitumen, crude oil products, coal tar, coal-tar pitch, coal-tar naphtha solvent, and sulfur, creosote, and creosote (wood). With temperatures up to 250°C in separated multi-section tanks and liquid density up to 1.8 t m3. The main structure, cargo tanks of Asphalt tanker | Bitumen Tanker intended for the max stress limits against hydrostatic and hydrodynamic worst-case scenario load cases.
Asphalt Tanker, Bitumen Tanker can load and maintain up to 250°C in fully segregated tanks, each tank block also has an integrated pump room. Pumps can discharge a full cargo in less than 24 hours, with pumping rates up to 2,000 m³/hour. All cargo pipes, cargo pumps, cargo ventilation lines, and valves are heat traced by thermal oil pipes and insulated. Pipes on deck are to be covered by protection. All pipes in cargo tanks are to be double-walled with heating thermal oil in the space between.
Asphalt tanker | Bitumen Tanker capacities can be arranged up to 20.000 m3. Dimensions, specs can be configured for specific locations or customer needs, requirements.
- Separated hull structure
- High-speed loading, discharging capacity up to 2,000 m³/hour.
- Monitoring system fitted in all cargo tanks.
- Both LNG + Marine Fuel Oils
- LNG dual-fuel (DF)
- Battery + LNG-fueled
|Asphalt 3500||Asphalt 6000||Asphalt 6825||Asphalt 11000||Asphalt 14000||Asphault 15200||Asphalt 18000|
|Lenght||97 m||105 m||110 m||129 m||135 m||135 m||156 m|
|Width||15.5 m||16 m||19 m||22 m||23 m||23 m||25 m|
|Depth||8 m||8 m||10 m||12 m||11 m||11 m||14 m|
|Speed||13 Knots||14 Knots||14 Knots||14 Knots||14 Knots||14 Knots||14 Knots|
|Cargo Capacity||3500 m3||6000 m3||6825 m3||11000 m3||14000 m3||3900 m3||18000 m3|
|Cargo Type||Asphalt / Balck Product||Asphalt / Balck Product||Asphalt / Balck Product||Asphalt / Balck Product||Asphalt / Balck Product||Asphalt / Balck Product||Asphalt / Balck Product|
|DWT||3500 T||6000 T||1600 T||11000 T||14000 T||15200 T||18000 t|
|Accommodation||18 Person||16 Person||18 Person||18 Person||32 Person||32 Person||19 Person|
